Features & Specifications
-
ASTM 316/316L stainless steel
- 3-PC body design facilitate inspection and easy inline repair
- Full port flow to tube ID without tapering
- Highly-polished 8-12 Ra ID
- Live loaded, self-adjusting packing and Belleville washers provide better sealing and defense against leaking
- 3-PC, v-ring stem packing for superior sealing and lower torque
- Blowout-proof, bottom entry stem design and anti-static device
- ANSI B16/B2/B18, MSS-SP82, NSF61 AWWA
- Body cavity fillers meet FDA, USDA, & 3A Requirements
- Designed for high cycle automated applications
- Standard TC ends; other ends available upon request
- 100% tested and inspected prior to shipping
- Full traceability of all components
- SST x PTFE seats available for high temperature applications
- Available in regular or cavity filled styles
- Standard seats are TFM-1600
- Cavity fillers are virgin PTFE (CFR 21 compliant)
- Cavity filled valves suitable for vacuum applications
|
 |
